Dc motor with encoder
1.Standard Operating Conditions
1-1 Rated Voltage:12v.
1-2 Direction of Rotation:CW when viewed from output shaft side
1-3Operating Temperature and Humidity:Temperature range of -10C~+50C,Humidity range of 30%~80%.
1-4Storage Temperature:Temperature range of -20C~+60C
2.Measuring Conditions:
2-1Motor Position:To be place t horizontally when measuring
2-2Power Supply: Regulated DC power supply
--No load speed:8.6rpm-977rpm.
--Robotics, Small Appliance, Fanner, Electric Curtain;
--Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Machine; Electric Valve, Actuator, medical device
--Electric motor,low noise,low current and no spark.
| voltage | no load | AT MAXIMUM EFFICIENCY | stall | reducer | weight |
| workable | rated | speed | current | speed | current | torque | output | torque | current | ratio | size |
|
| range | volt.v | rpm | ma | rpm | ma | kg.cm | w | kg.cm | A | 1:00 | mm | g |
| 6-24v | 12 | 977 | 46 | 781 | 300 | 0.11 | 1.25 | 0.55 | 1 | 4.4 | 15 | 80 |
| 6-24v | 12 | 463 | 46 | 370 | 300 | 0.23 | 1.25 | 1.1 | 1 | 9.28 | 17 | 82 |
| 6-24v | 12 | 201 | 46 | 168 | 250 | 0.53 | 1.25 | 2.65 | 1 | 21.3 | 19 | 84 |
| 6-24v | 12 | 126 | 46 | 100 | 250 | 0.85 | 1.25 | 4.2 | 1 | 34 | 21 | 85 |
| 6-24v | 12 | 95 | 46 | 76 | 200 | 1.1 | 1.25 | 5.5 | 1 | 45 | 21 | 86 |
| 6-24v | 12 | 55 | 46 | 44 | 200 | 1.95 | 1.25 | 9.7 | 1 | 78 | 23 | 88 |
| 6-24v | 12 | 41 | 46 | 32 | 150 | 2.5 | 1.25 | 12.5 | 1 | 103 | 23 | 89 |
| 6-24v | 12 | 25 | 46 | 20 | 150 | 4.2 | 1.25 | 21 | 1 | 171 | 25 | 91 |
| 6-24v | 12 | 19 | 46 | 15 | 120 | 5.6 | 1.25 | 28 | 1 | 226 | 25 | 92 |
| 6-24v | 12 | 11 | 46 | 8.8 | 120 | 9.45 | 1.25 | 47 | 1 | 378 | 27 | 94 |
| 6-24v | 12 | 8.6 | 46 | 6.8 | 120 | 12 | 1.25 | 60 | 1 | 500 | 27 | 96 |
Important! Pls confirm the parameter and you want to customize such as shaft size,speed etc ,pls feel free to contact our salers.
